You've got a high-draw GPU and a build that needs headroom without the fan noise. The Gigabyte UD1000GM PG5 ICE delivers 1000W at 80 PLUS Gold (90% typical load efficiency), so your rig draws less from the wall and runs cooler at the PSU level.
PCIe Gen 5.0 and Intel ATX 3.0 support mean that 16-pin power connector is native — no dodgy adapters. Japanese main capacitors, a 120mm hydraulic bearing fan, and an MTBF past 100,000 hours keep it quiet and reliable day in, day out.
Fully modular flat black cables let you skip the ones you don't need. Compact at 150 × 140 × 86 mm, it slots into most mid-tower cases without eating drive bays. Six protection circuits guard against over-voltage, over-power, short circuit, under-voltage, over-current, and over-temperature events.
If you're mid-build and the PSU is the last part holding you up, this is the one that just works. Call us if your case is tight on clearance — we'll confirm it fits before you commit
| atx_mb_20_4_pin | 1 × 610mm |
| cpu_eps_4_4_pin | 2 × (600mm + 200mm) |
| pci_e_16_pin | 1 × 700mm |
| pci_e_6_2_pin | 4 × (600mm + 150mm) × 2 |
| sata | 8 × (600mm+150mm+150mm+150mm × 2) |
| 4_pin_peripheral | 3 + 1 floppy × (500mm+120mm+120mm+150mm) |
| brand | GIGABYTE |
| model | GP-UD1000GM PG5 |
| wattage | 1000W |
| form_factor | ATX 12V |
| efficiency_rating | 80 PLUS Gold (90% at typical load) |
| pfc | Active PFC (>0.9 typical) |
| input_voltage | 100–240 Vac full range |
| input_current | 15–6.5A |
| input_frequency | 50–60 Hz |
| dimensions_mm | 150 × 140 × 86 |
| fan | 120mm Hydraulic Bearing (HYB) |
| cable_type | Flat, all black, fully modular |
| single_12v_rail | 1 |
| pci_e_gen5_support | 1 |
| atx_3_0_compliant | 1 |
| mtbf_hours | >100,000 |
| protection | OVP / OPP / SCP / UVP / OCP / OTP |
| power_good_signal_ms | 100–150 |
| hold_up_time_ms | >16 |
| warranty_years | 10 |
