You want a board that just works. Plug in your Ryzen 9000, drop two sticks of DDR5, and build without second-guessing every slot allocation. The MAG X870 Tomahawk WIFI does exactly that. Four M.2 slots so you can run a fast NVMe for your OS, a second for projects, and still keep SATA drives for bulk storage. Three PCIe x16 physical slots (mixed Gen) give you flexibility if you add a capture card or a secondary GPU later. Wi-Fi 7 with Bluetooth 5.4 and MLO support means stable connections even in a dense apartment block. USB4 on two Type-C ports handles your display and peripherals in one cable. The EZ Debug LEDs tell you exactly what's not posting when something goes sideways at 11pm. ATX form factor, 304.8 x 243.84mm – fits standard mid-towers. Add to cart and we'll get it moving
| brand | MSI |
| model | MAG X870 TOMAHAWK WIFI |
| chipset | AMD X870 |
| socket | AM5 |
| cpu_support | AMD Ryzen 9000 / 8000 / 7000 Series Desktop |
| memory_type | DDR5 UDIMM |
| memory_slots | 4 |
| max_memory_gb | 256 |
| m2_slots | 4 |
| sata_ports | 4 |
| pcie_x16_slots | 3 |
| wireless | Wi-Fi 7 (MLO, 4KQAM), Bluetooth 5.4 |
| lan | Realtek 8126-CG 5G LAN |
| usb_ports | 2x USB4 Type-C, multiple USB 3.2 and USB 2.0 |
| audio | Realtek ALC4080, 7.1-Channel USB High Performance Audio |
| display_output | HDMI 2.1 FRL (8K@60Hz), 2x Type-C USB4 (DP 1.4 HBR3, 4K@60Hz) |
| raid_support | RAID 0, RAID 1, RAID 10 (M.2 NVMe) |
| form_factor | ATX |
| dimensions_mm | 304.8 x 243.84 |
| os_support | Windows 11 64-bit |
