You need a yellow status light that reads clearly from a normal viewing angle, not a pinprick you have to lean in to see. This Jaycar 5x2mm rectangular diffused yellow LED hits 10mcd with a 155° viewing angle and a 590nm wavelength — warm, readable yellow without tipping into orange. Runs at 20mA max with a 1.9V forward voltage. The datasheet lists your series resistor for 5V (160Ω), 9V (360Ω), and 12V (510Ω) so you can wire it the first time, not the third. On the shelf, ready to ship. Add to cart
| brand | Jaycar |
| colour | Yellow |
| lens_shape | Rectangular |
| lens_finish | Diffused |
| size_mm | 5x2 |
| brightness_mcd | 10 |
| viewing_angle_degrees | 155 |
| wavelength_nm | 590 |
| forward_current_typical_ma | 20 |
| forward_voltage_typical_v | 1.9 |
| max_continuous_current_ma | 20 |
| series_resistor_5v_ohms | 160 |
| series_resistor_9v_ohms | 360 |
| series_resistor_12v_ohms | 510 |
