Your project needs fine positioning without the jitter of a basic DC motor. This 48-step stepper delivers 7.5° resolution per step in a compact flange-mount package. Four-phase unipolar chopper drive means smooth, repeatable motion straight from your driver board. The 3.0mm hardened steel shaft won't wear out on your first thousand cycles. Bolt it down, wire it up, get precise movement without the guesswork
| brand | JAYCAR |
| rated_voltage | 12VDC |
| rated_current | 1.1A/phase |
| phases | 4 |
| steps_per_revolution | 48 |
| stepping_angle | 7.5° |
| drive_method | Unipolar chopper drive |
| resistance_per_winding | 20 ohms |
| max_starting_frequency | 600pps |
| holding_torque | 700g/cm |
| shaft_diameter | 3.0mm |
| shaft_material | Hardened steel |
| mount_type | Flange |
