Mean Well PWM-120-24 | 24V 120W LED Power Supply with PWM Dimming | IP67 | 5-Year Warranty

SKU: MP4181
$149.00
inc. GST
Available to Order
Order now to secure stock from our supplier.
Secure
Payment
Fast
Shipping
Easy
Returns
Authentic
Stock

Key Features

24VDC constant-voltage output at 5A / 120W with 0–100% PWM dimming
IP67-rated plastic housing (Class II) — rain, dust, and splash proof
Short-circuit, overload, and overvoltage protection as standard
No-load power consumption under 0.5W; operating range -40°C to 90°C
Accepts 90–305VAC or 127–431VDC input; inrush current 60A @ 230VAC
Includes customised input lead; 5-year warranty

Product Overview

Your LED strip is flickering, dimming unevenly, or you're running a 24V sign that needs to actually stay on. This Mean Well PWM-120-24 handles 120W of constant-voltage output at 24VDC with smooth 0–100% PWM dimming. IP67-rated housing means it shrugs off rain, dust, and the occasional hose-down in the car park. You get short-circuit, overload, and overvoltage protection built in, so one bad connection doesn't take out your whole rig. Customised input lead included — plug it in, set your dim level, done. 5-year warranty. No load draw under 0.5W, so it's not sipping power while you're asleep. Runs from -40°C to 90°C, which covers every Australian outdoor install. Ships from AU stock

Key Features

  • 24VDC constant-voltage output at 5A / 120W with 0–100% PWM dimming
  • IP67-rated plastic housing (Class II) — rain, dust, and splash proof
  • Short-circuit, overload, and overvoltage protection as standard
  • No-load power consumption under 0.5W; operating range -40°C to 90°C
  • Accepts 90–305VAC or 127–431VDC input; inrush current 60A @ 230VAC
  • Includes customised input lead; 5-year warranty

Specifications

brand JAYCAR / Mean Well
model PWM-120-24
output_voltage 24VDC
output_current 5A
power_rating 120W
dimming_range 0-100% PWM
input_voltage 90-305VAC / 127-431VDC
input_frequency 47-63Hz
inrush_current 60A @ 230VAC
ip_rating IP67
housing Plastic, Class II
no_load_consumption <0.5W
operating_temperature -40 to 90°C
dimensions_mm 191(L) x 63(W) x 37.5(H)
warranty 5 years
includes Customised input lead
