Binary Coded DIL Rotary Switch – Hex, Sealed PCB Mount | Jaycar

Building a board and you need a compact rotary that survives vibration without shedding solder joints? This binary coded hex DIL rotary is built for exactly that. Pins are moulded in and fully sealed – no wobble, no cold joints hiding in the layout. Body is UL 94V-0 flame retardant plastic, so it plays nice next to your other components. Rated for 25mA switching at 24VDC and 100mA non-switching at 50VDC. Torque requirement is 500gf-cm. Solder at 230 ±5°C for 5 seconds. Small, sealed, rated. Drop it in and move on

• Fully sealed with moulded-in pins – no loose leads to misalign
• UL 94V-0 flame retardant plastic body
• Switching rating: 25mA @ 24VDC / Non-switching: 100mA @ 50VDC
• Rotational torque required: 500gf-cm
• Vibration rated per MIL-STD-202F Method 204D
• Solderability: 230 ±5°C for 5 ±0.5 sec after flux
