Jaycar 8-Pin 0.1in Header with Crimp Pins – 2.54mm Pitch PCB Connector

Eight lines to connect and your breadboard's getting crowded. The Jaycar HM3408 is an 8-way, 2.54mm-pitch header that bolts the connection into place — literally, with a locking key so it can't go in the wrong way. Square tin-plated brass pins protrude 3.4mm for a solid solder joint on the board. White nylon wafer, 3.3mm thick, UL 94V-0 rated. Stack boards end-to-end or mount at 90° to save space. Rated 0 to +75°C. Eight clean connections, zero guesswork

• 8-pin wafer header with square tin-plated brass crimp pins, 2.54mm (0.1in) pitch
• Pins protrude 3.4mm for reliable through-hole soldering; nylon wafer is 3.3mm thick
• UL 94V-0 rated white nylon housing; locking and polarising key on the back
• Mates boards end-to-end or at right angles; plugs butt together for any pin count from 2 up
• Normal mating force 200g min; rated 0 to +75°C
