Jaycar 10-Pin 0.1in Header with Crimp Pins – 2.54mm Pitch PCB Connector

Ten signals and you've had enough of daisy-chaining wires. The Jaycar HM3410 gives you a 10-way, 2.54mm-pitch header that seats on the board and locks when mated — no wobble, no backwards plug-in. Square tin-plated brass pins protrude 3.4mm for a clean through-hole solder. White nylon wafer, 3.3mm thick, UL 94V-0 rated. Run boards end-to-end or at right angles to match your layout. Rated 0 to +75°C. Ten connections in one go, and you can butt another header on the other side if you need more ways

• 10-pin wafer header with square tin-plated brass crimp pins, 2.54mm (0.1in) pitch
• Pins protrude 3.4mm for reliable through-hole soldering; nylon wafer is 3.3mm thick
• UL 94V-0 rated white nylon housing; locking and polarising key on the back
• Mates boards end-to-end or at right angles; plugs butt together for any pin count from 2 up
• Normal mating force 200g min; rated 0 to +75°C
