6-Pin Straight Locking PCB Header – 2.54mm Pitch | Jaycar HM3416

Six pins between boards or from a cable to your PCB, and you need it now, not in six days' time. This is the part: square tin-plated brass pins at 2.54mm pitch, 3.4mm solder lead for a clean through-hole joint. The UL 94V-0 nylon wafer sits at 3.3mm thick on your board face. Locking and polarised back means the mating plug stays put and can't be reversed. Plug boards together at right angles or end-to-end, or run a cable in at the edge. Buttable if you need to stretch the run. RRP $5.00. Solder it in and get back to building

• 6-pin straight through-hole header, 2.54mm (0.1in) pitch
• Square tin-plated brass pins with 3.4mm solder lead for solid PCB joints
• UL 94V-0 white nylon housing, 3.3mm wafer thickness
• Locking and polarised back prevents misalignment and vibration pull-out
• Minimum contact force 200g; rated 0 to +75°C
• Buttable end-to-end for multi-way board-to-board or cable connections
