Jaycar 10A Panel Mount Thermal Circuit Breaker, 19mm Square Facade, Red Trip Button, IEC 934 R/TO

That 10A circuit on your panel shouldn't need a fuse change every time the motor kicks in. This Jaycar thermal breaker mounts in a standard 19mm square hole. Black facade, one red trip button in the middle. Overcurrent? Button pops out. Fault cleared? Push it back in. Sorted. The slow-response curve is purpose-built for inductive and reactive loads, so you won't get nuisance trips on startup surges. IEC 934 Type R/TO. Holds 10A at full load indefinitely. Trips within 1 hour at 135% load, within 1 minute at 200% load. Contact resistance 0.16 ohms

• 10A rated, holds 100% load indefinitely without tripping
• Slow-response thermal design suits inductive and reactive loads (motors, transformers)
• 19mm square black facade with central red trip/reset button
• Trips within 1 hour at 135% load or within 1 minute at 200% load
• IEC 934 Type R/TO compliant, contact resistance 0.16 ohms
