Mid-repair on a stereo amp or mixing board and the 50K linear double-gang pot's shot. You need the matched pair, not two mismatched singles that'll drift out of balance. This 9mm unit gives you both channels, 300° sweep, 50VAC headroom. Solder it in, check tracking, and you're back on the bench doing actual work
| brand | Jaycar |
| ohm_value | 50K |
| taper | Linear (B) |
| gang | Double |
| body_size_mm | 9 |
| rated_power_w | 0.05 |
| rated_voltage | 50VAC |
| slider_noise | <100mV |
| insulation_resistance | >100MΩ at 250VDC |
| dielectric_rating | 300VAC/minute |
| tracking_error | Within 3dB at 40~0dB |
| rotation_angle | 300° ± 5° |
| rotation_torque | 20–250 gf·cm |
| shaft_stop_strength | 5 kgf·cm/min |
