You've got a half-rack of gear humming away and zero margin when the substation stumbles. A 2U unit that keeps your switch, server, and storage alive without eating three rack slots. That's what this one does.
The SRV2KRI is a double-conversion on-line UPS rated at 2000VA / 1600W. Pure sine wave out, every cycle. No transfer gap between mains and battery because it's always converting. Four IEC C13 outlets on the back. IEC C14 input. Plug in, rack it, done.
The LCD gives you real-time status. The intelligent card slot takes an AP9544, SRVSMB001, or VGL9901I if you want to watch it from your monitoring stack. Auto and manual bypass are built in, so a fault inside the UPS doesn't pull the plug on your load.
Input range handles 110–285V at half load and 160–280V at full load. Frequency auto-senses 40–70Hz. Sits at 230V nominal output. Rail kit is in the box. If your computer room, small data centre, or clinic IT setup needs clean power in a tight footprint, this is the straightforward answer
| 0 | AP9544 |
| 1 | SRVSMB001 |
| 2 | VGL9901I |
| brand | APC |
| model | SRV2KRI |
| rated_power_va | 2000 VA |
| rated_power_w | 1600 W |
| rack_units | 2U |
| input_voltage | 230 V AC single-phase (220/240 V configurable) |
| output_voltage | 230 V AC single-phase |
| input_connector | IEC 60320 C14 |
| output_connectors | 4x IEC 60320 C13 |
| ups_topology | On-line (double-conversion) |
| waveform | Pure sine wave |
| bypass | Internal automatic and manual |
| control_panel | Multifunction LCD |
| expansion_slot | 1 intelligent card slot |
| replacement_battery | APCRBCV201 |
| input_voltage_range_half_load | 110–285 V |
| input_voltage_range_full_load | 160–280 V |
| network_frequency | 40–70 Hz auto-sensing |
| cable_length | 1.5 m |
| mounting_kit | 1x rack brackets, 1x support rails |
| operating_temp | 0–40 °C |
| storage_temp | -20–50 °C |
| humidity | 0–95% non-condensing |
| acoustic_level | 50 dBA |
| heat_dissipation | 745 Btu/h |
| ip_rating | IP20 |
| operating_altitude | 0–3000 m |
