Three minutes of backup isn't enough when your storage array needs a full graceful shutdown cycle. You've been burned by the short-runtime unit that beeps, gives you 90 seconds, and then your data's in limbo.
This is the extended-runtime version of the APC SRV tower UPS. Same 3kVA / 2700W of double-conversion online power, same pure sine wave output, but the battery pack is sized to give your kit a longer, calmer runway when the mains drops. No panic. No forced shutdowns mid-write.
The LCD on the front tells you exactly where you stand — load percentage, remaining runtime, battery health. No decoding LED codes at 7am. The intelligent card slot takes an AP9544, SRVSMB001, or VGL9601l so your NOC or IT team can see this unit from the dashboard without walking to the server room.
Internal automatic and manual bypass means even a fault inside the UPS won't pull the plug on your load. 230V single-phase input, standard AU mains. Two-year warranty on the unit and battery.
Add to cart and stop dreading the next brownout
| brand | APC |
| series | Easy UPS SRV |
| model | SRV3KIL-E |
| ups_type | Online (Double Conversion) |
| rated_capacity_va | 3000 VA |
| rated_power_w | 2700 W |
| form_factor | Tower |
| input_voltage | 230V AC single phase (220V / 240V configurable) |
| input_connection | IEC 60320 C20 |
| input_voltage_limits_40pct_load | 105–300 V |
| input_voltage_limits_full_load | 180–285 V |
| output_voltage | 230V AC single phase (220V / 240V configurable) |
| output_connections | 6× IEC 60320 C13, 1× IEC 60320 C19 |
| waveform | Sine wave |
| efficiency_full_load | 90 % |
| bypass | Internal (automatic and manual) |
| crest_factor | 3:1 |
| harmonic_distortion | 3 % |
| output_frequency | 50/60 Hz ±3 Hz, sync to mains |
| network_frequency_input | 40–70 Hz auto sensing |
| battery_type | Lead-acid (internal, included) — extended runtime |
| control_panel | Multifunction LCD status and control console |
| expansion_slots | 1 |
| connectivity | Serial port, USB port, 1 expansion slot |
| compatible_nmc | AP9544, SRVSMB001, VGL9601l |
| mounting_mode | Tower |
| warranty | 2 years (UPS unit and built-in lead-acid battery) |
| category | ELECTRONICS & COMPONENTS |
| subcategory | POWER & BATTERIES |
