Your server rack is full of gear that can't afford a single voltage dip. This 5U rackmount UPS hardwires in with a 3-wire (1P+N+E) connection on both input and output — no extension leads, no socket daisy-chaining. 10kVA of pure sine wave power, 94% efficiency at full load, built-in automatic and manual bypass. Rail kit, brackets, and support rails are in the box. At full 10kW load the included battery pack gives you 2 minutes 32 seconds; add an SRV240RLBP-9A for extended runtime. Monitors through EcoStruxure IT or third-party platforms. Power cable not included
| 0 | AP9544 |
| 1 | SRVSMB001 |
| 0 | SRV240RLBP-9A |
| brand | APC |
| category | ELECTRONICS & COMPONENTS |
| subcategory | POWER & BATTERIES |
| product_type | Online UPS (Rackmount) |
| rated_power_va | 10000 |
| rated_power_w | 10000 |
| input_voltage | 230V (110-300V range) |
| output_voltage | 230V (configurable 220/230/240V) |
| ups_type | Double conversion online |
| wave_type | Sine wave |
| efficiency_full_load | 94% |
| output_connector | Hard wire 3-wire (1P+N+E) x1 |
| input_connector | Hard wire 3-wire (1P+N+E) x1 |
| bypass | Internal (automatic and manual) |
| rack_units | 5U |
| runtime_10kw | 2 min 32 s |
| acoustic_level_dba | 58 |
| ip_rating | IP20 |
| operating_temp_c | 0 to 40 |
| mounting | Rack mounted (5U) |
| in_the_box | 1 USB cable, 1 RS-232 configuration cable, 2 rack mounting brackets, 2 rack mounting support rails, 1 external battery pack, 1 battery cable, user manual |
