Three minutes of runtime sounds fine until you realise your backup job needs eight. Or your clean shutdown sequence takes longer than the battery can hold. Then you're doing a hard power-off and hoping nothing's corrupted.
The APC Easy UPS SRV1KIL-E solves that. Same double-conversion online topology, same pure sine wave output, but it ships with an extended battery pack bolted on. You get real time to finish what your gear is doing before it goes quiet.
Tower form factor. Three IEC C13 outlets. IEC C14 input. 230V single phase. LCD panel for voltage, load, and battery state. Connects to EcoStruxure IT or your existing monitoring stack so you're not flying blind during an outage.
Automatic and manual bypass are built in. Internal fault? Power reroutes. Your load keeps running.
The extended battery pack is included in the box along with a dedicated battery cable. Lead-acid chemistry, drop-in design.
In the box: IEC C13-to-Schuko cable, IEC C13-to-C14 cable, USB cable, RS-232 configuration cable, battery cable, user manual.
Compatible NMC cards: AP9544, SRVSMB001, VGL9901I.
Add to cart and give your critical systems the time they actually need to shut down clean
| 0 | AP9544 |
| 1 | SRVSMB001 |
| 2 | VGL9901I |
| 0 | 1x IEC C13 to Schuko power cable |
| 1 | 1x IEC C13 to C14 power cable |
| 2 | 1x USB cable |
| 3 | 1x RS-232 configuration cable |
| 4 | 1x battery cable |
| brand | APC |
| model | SRV1KIL-E |
| type | Online Double-Conversion UPS with Extended Battery Pack |
| form_factor | Tower |
| rated_power_va | 1000 VA |
| rated_power_w | 900 W |
| input_voltage | 230 V / 10 A (accepts 220–240 V) |
| output_voltage | 230 V (accepts 220–240 V) |
| input_connection | IEC 60320 C14 |
| output_outlets | 3x IEC 60320 C13 |
| cable_length | 1.5 m |
| network_frequency | 40–70 Hz auto sensing |
| input_voltage_limits | 110–285 V (half load), 160–280 V (full load) |
| operating_temperature | 0–40 °C |
| storage_temperature | -20–50 °C |
| humidity | 0–95% non-condensing |
| operating_altitude | 0–3000 m |
| acoustic_level | 50 dBA |
| heat_dissipation | 372 Btu/h |
| ip_rating | IP20 |
| mounting | Not rack mountable |
| battery_type | Lead-acid with extended battery pack |
| management | EcoStruxure IT or third-party platforms |
| bypass | Automatic and manual |
