A power blip shouldn't take your server room down. This 3kVA on-line UPS sits between the wall and your gear, delivering clean pure sine wave power through the whole outage — not just a brief transfer window.
True double-conversion means zero interruption. The preinstalled Network Management Card lets you watch voltage, load, and battery health from anywhere. PowerChute handles graceful shutdown across physical servers, VMs, and HCI clusters so nothing corrupts mid-write.
2U rackmount. 8x C13 plus 2x C19 outlets, two IEC jumpers in the box. Rail kit included. Plug in via BS1363A, IEC C20, or Schuko — your call. 2700W rated output at 230V.
Replacement battery: APCRBC152. Pairs with AP6003A, AP6015A, AP6020A, AP6120A, and AP7552 PDUs
| brand | APC |
| rated_power_va | 3000 VA |
| rated_power_w | 2700 W |
| input_voltage | 230V (also 220V, 240V) |
| output_voltage | 230V (also 220V, 240V) |
| rack_units | 2U |
| input_connections | BS1363A British, IEC 60320 C20, Schuko CEE 7/EU1-16P |
| output_connections | 8x IEC 60320 C13, 2x IEC 60320 C19, 2x IEC jumpers |
| cable_length | 2.44 m |
| ip_rating | IP20 |
| acoustic_level | 55 dBA |
| heat_dissipation | 703 Btu/h |
| operating_temperature | 0–40 °C |
| storage_temperature | -15–45 °C |
| humidity_range | 0–95% non-condensing |
| replacement_battery | APCRBC152 |
| compatible_pdus | AP6003A, AP6015A, AP6020A, AP6120A, AP7552 |
| compatible_service_bypass | SBP3000RMHW, SBP3000RMI, SBP5000RMI2U |
| compatible_sensors | AP9335T, AP9335TH |
| compatible_nmc | AP9613, AP9620, AP9640, AP9641, AP9643, AP9810 |
| compatible_mounting | SRTRK3, SRTRK4 |
| included_items | CD with software, documentation CD, installation guide, network management card, rack mounting brackets, rack mounting support rails, USB cable, warranty card |
