Eight kilowatts of on-line protection in a 6U rack slot. If your server farm or lab bench is drawing more than the 6kW can hold, this is the step up without jumping to a whole different platform.
True double-conversion on-line topology. Zero transfer time. Your load never sees the grid hiccup. Input accepts 230 V single-phase or 400 V three-phase (3:1 and 1:1 wiring), so it slots into either a standard office feed or a dedicated three-phase sub-feed in a data room.
Six C13 and four C19 IEC outlets, plus hard-wired 3-wire/5-wire input. Embedded Web/SNMP management card for remote monitoring. SmartSlot for adding a wireless adapter or extra connectivity later. Extended runtime with the SRT192RMBP2 battery.
IP20, 55 dBA, 0–40 °C operating range. RCM certified. Rail kit, brackets, and support rails all in the box. Rack it, wire the input, and you're protected before the next power event
| brand | APC |
| model_range | Smart-UPS On-Line (SRT) |
| capacity_va | 8000 VA |
| capacity_w | 8000 W |
| form_factor | Rackmount 6U |
| input_voltage | 230 V / 400 V 3-phase (3:1 and 1:1); also accepts 220 V, 240 V, 380 V, 415 V |
| output_voltage | 230 V (also 220 V, 240 V) |
| wave_type | Pure sine wave |
| topology | Double-conversion on-line |
| outlets | 6× IEC 60320 C13, 4× IEC 60320 C19, 3× IEC jumpers |
| input_connector | Hard wire 3-wire / 5-wire |
| management | Embedded Web/SNMP card + SmartSlot |
| compatible_battery | SRT192RMBP2 |
| replacement_battery | APCRBC140 |
| compatible_wireless_adapter | AP9834 |
| ip_rating | IP20 |
| acoustic_level | 55 dBA |
| heat_dissipation | 1497 Btu/h |
| operating_temp | 0–40 °C |
| storage_temp | -15–45 °C |
| humidity | 0–95% non-condensing |
| certifications | CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE |
| operating_altitude | 0–10000 ft |
| includes | CD with software, documentation CD, installation guide, rack mounting hardware, brackets, support rails, temperature probe, USB cable, warranty card, Web/SNMP management card |
