You've been staring at your energy bill and wondering which server in the rack is quietly eating your budget. This PDU tells you, outlet by outlet, exactly what's drawing volts, amps, kW, and kWh — in real time, from anywhere.
The APC NetShelter Metered-by-Outlet Rack PDU sits at 0U, takes a single 7.4kW, 230V, 32A feed, and hands you 21× IEC C13 plus 3× IEC C19 outlets with per-outlet metering. You see the load. You set the alarm threshold. It warns you before the circuit trips and takes down critical gear at 6am on a Tuesday.
Manage it over EcoStruxure IT, Web, SNMP, or CLI. Pull historical reports to plan capacity or justify that extra UPS to finance. Runs from -5°C to 60°C, so the unventilated server room in the back of the warehouse won't be an issue.
Ships with rack mounting brackets, a CAN port terminator, and a serial configuration cable. Plug it in, set your alarms, and stop guessing
| brand | APC |
| product_type | PDU |
| pdu_subtype | Metered by outlet |
| phase | 1PH |
| power_rating_kw | 7.4 |
| voltage_v | 230 |
| current_a | 32 |
| outlets_c13 | 21 |
| outlets_c19 | 3 |
| rack_units | 0U |
| cord_length_m | 3 |
| input_voltages | 200V, 208V, 230V |
| colour | Black |
| certifications | VDE |
| standards | EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3 |
| operating_temp_range_c | -5 to 60 |
| storage_temp_range_c | -25 to 65 |
| relative_humidity_percent | 5 to 95 |
| operating_altitude_ft | 0 to 10000 |
| compatible_mounting | AR7711 |
| compatible_pdus | AP8000BLU, AP8000RED, AP8702R-WW, AP8702S-WW, AP8702S-WWX340 |
| compatible_sensors | AP9335T, AP9335TH |
