Your 5G router is sitting in a cabinet or on a vehicle roof and the signal's still patchy. Or your GNSS fix keeps drifting because the antenna was an afterthought. This Teltonika 5G combo kills both problems in one IP67-rated unit. Four MIMO channels cover 600 MHz through 5 GHz, so you're not stuck on one band when the network shifts. The GNSS side gives you a locked position with 17 dB LNA gain and a noise figure under 2 dB. Mount it with an M6 screw or adhesive, route the 3-metre LMR100 cable, and you're done. Handles -40 °C to +80 °C, so a Queensland summer or a Victorian winter won't shift your specs
| brand | Teltonika |
| antenna_type | Combo 5G MIMO Mobile/GNSS |
| mounting | M6 screw or adhesive |
| enclosure_material | PC/PC+ABS |
| ip_rating | IP67 |
| uv_resistant | 1 |
| operating_temperature | -40 °C to +80 °C |
| operating_humidity | ≤ 90 % |
| cable_length_mm | 3000 |
| cable_type | LMR100 |
| weight_g | 450 |
| mobile_frequency_range_mhz | 600–960, 1427–2700, 3300–4200, 4400–5000 |
| mobile_polarisation | Linear |
| mobile_radiation_pattern | Omni-directional |
| mobile_gain_dbi | ≤ 4 |
| mobile_vswr | ≤ 2.5 |
| mobile_impedance_ohm | 50 |
| mobile_connectors | 4 × SMA Male |
| gnss_frequency_range_mhz | 1559–1610, 1164–1189 |
| gnss_polarisation | RHCP |
| gnss_radiation_pattern | Directional |
| gnss_gain_dbi | ≤ 2 |
| lna_gain_db | 17 ± 2 |
| lna_noise_figure_db | ≤ 2 |
| gnss_vswr | ≤ 2 |
| gnss_impedance_ohm | 50 |
| gnss_supply_voltage_vdc | 3–5 |
| gnss_current_ma | 15 |
| gnss_connectors | 1 × SMA Male |
| rohs_compliant | 1 |
| category | Electronics & Components |
| subcategory | Automation & Security |
