You've got the router, you've picked the spot on the roof or the vehicle panel, and now you need one clean dome instead of three separate sticks. But your cabling run is custom – maybe it's going through a conduit, under a seat, or across a bulkhead to a specific patch panel.
This is the PANORAMA MAKO 5G Dome in white. Four isolated MIMO elements handle 4G/5G across 617–960 MHz and 1710–6000 MHz. Two additional elements cover 2.4 GHz WiFi. One GPS/GNSS module with a built-in 26 dB LNA keeps your position lock tight. All in a single 80 mm dome.
Cables come loose at five metres each – FR RG174, flame-retardant, UN ECE R118 compliant. You terminate them to whatever connector your install needs: SMA (m) on the cellular side, Reverse Polarity SMA on WiFi, SMA (m) on GPS. Cable flags are attached so you're not guessing which is which at the other end.
No metallic ground plane needed. Mount it on fibro, steel, or a composite roof and it still performs. IK10 impact rated. IP69K sealed. -40 °C to +80 °C. Single-hole panel mount or magnetic for a temp install while you finalise the layout.
If your cabling run is non-standard and you need to terminate it yourself, this is the dome that gives you the flexibility without sacrificing spec
| brand | PANORAMA |
| colour | White |
| cellular_mimo | 4×4 MIMO |
| wifi_mimo | 2×2 MIMO (2.4 GHz) |
| gps_gnss | Yes – 1 module, 26 dB LNA, 1562–1612 MHz |
| frequency_range_cellular | 617–960 MHz / 1710–6000 MHz |
| gain_cellular | 4 dBi (617–960 MHz), 8 dBi (1710–3800 MHz), 9 dBi (4900–6000 MHz) |
| max_input_power | 10 W |
| cable_length | 5 m (loose) |
| cable_type | FR RG174 |
| connector_cellular | SMA (m) |
| connector_wifi | Reverse Polarity SMA |
| connector_gps | SMA (m) |
| ip_rating | IP69K |
| ik_rating | IK10 |
| operating_temperature | -40 °C to +80 °C |
| mounting | Panel / Magnetic |
| height | 80 mm |
| diameter | 180 mm |
| pattern | Omnidirectional |
| ground_plane_required | No |
| cable_flammability | UN ECE R118, EN45545-2 HL3, EN6722 |
| quantity_cell_cables | 4 |
| quantity_gps_cables | 1 |
| quantity_wifi_cables | 2 |
