Your fleet router keeps losing its 5G link the moment it parks under a tree or in a covered car park. You've got a Cat 18 or Cat 20 router that's capable, but the antenna on top can't keep up.
The PANORAMA MAKO 5G Dome gives you four isolated high-performance elements covering 617–960 MHz, 1710–3800 MHz, and 4900–6000 MHz in a single low-profile dome. Up to 11 functions in one housing: 4x4 MIMO cellular, optional 2x2 through 6x6 MIMO WiFi at 2.4/5.0/7.2 GHz, and an optional GPS/GNSS module with 26 dB LNA.
No metallic ground plane required. It performs on plastic, composite, or painted vehicle surfaces. Cables are flame-retardant, UNECE R118 compliant, 0.3 to 5 metres (selectable), pre-terminated as standard.
Dome is 180 mm diameter, 80 mm tall. Black or white. Operating range -40° to +80°C. Max input power 10 W.
Add to cart and we'll get it out to you
| brand | PANORAMA |
| pattern | Omnidirectional |
| max_input_power_w | 10 |
| frequency_range_gain | 617–960 MHz | 4 dBi; 1710–3800 MHz | 8 dBi; 4900–6000 MHz | 9 dBi |
| cellular_elements | 4 x 4 MIMO |
| wifi_elements | Optional: 2x2, 3x3, 4x4, 5x5, or 6x6 MIMO (2.4/5.0/7.2 GHz) |
| gps_frequency_mhz | 1562–1612 |
| lna_gain_db | 26 |
| colour | Black / White |
| diameter_mm | 180 |
| height_mm | 80 |
| operating_temperature_c | -40 to +80 |
| cable_length_m | 0.3 to 5 |
| cable_standard | UNECE R118 |
| ground_plane_required | No |
